VIDEO: Foxeer Cat 3 Night FPV Camera Review
Features of Foxeer Cat 3 Night Camera
- Quieter Operation
- Reduced Latency
- Specially Optimized for LED Lighting
- Switchable Aspect Ratios (4:3/16:9) & PAL/NTSC
- Wide-Aperture Night Vision Lens
- Supports OSD & Remote Menu Control with Foxeer FC
- More Compact than the Mini Cat 3
- 0.00001LUX Ultra Starlight Capability
Specifications
- Sensor Type: Sony 1/3″ CMOS Sensor
- Scale: 4:3(Default)/16:9 Switchable
- Tv System: PAL(Default)/NTSC Switchable
- Resolution: 1200TVL camera
- Lens: M12 2.1mm Low Light Lens
- FOV: 4:3 FOV-H: 100° FOV-D:125° 16:9 FOV-H: 100° FOV-D:115°
- Shutter Speed: PAL 1/25-1/10000 sec, NTSC 1/30-1/10000 sec
- Video Output: CVBS Analog Signal
- Minimum Illumination: 0.00001Lux
- White Balance: Auto
- DNR: 3DNR
- WDR: 100dB
- DAY/NIGHT: EXT/Auto/Color/B&W
- Flight OSD: Voltage/Cam Title/Time
- Input Voltage: 4.6V~20V
- Language: ENGLISH and 9 other languages
- Working Temperature: -10°~50°C RH90% MAX
- Working Humidity: 20~80%
- Storage Temperature: -20°~70°C
- Consumption: 95mA±15% @ DC12V
- Dimension: 19*19mm
- Weight: 10.7g (Excluding cable)
Includes
- 1x Foxeer Micro Cat 3 Camera
- 1x Hardware Set
- 1x OSD Board
- 1x 2-Pin OSD Cable
- 1x Servo Cable
Download Manual
Quadkart is one of the best FPV Camera store in India, click here to view more cameras.
