The RadioMaster RP1 ExpressLRS 2.4GHz Nano Receiver w/ 65mm UFL T-Antenna is an open-source receiver based on ExpressLRS. It features an ESP8285 MCU and an SX1280 RF chip. The RP1 has a UFL antenna socket for full-range antenna use and WIFI built in so you can upgrade firmware by WIFI and configure the Receiver via the built-in WebUI with your PC or mobile phone. Due to the low-latency and high-refresh-rate RF module, the RP1 is ideal for FPV racing or Long Range flights. Suitable for Whoops, drones, and fixed-wing models due to the ultra-light and nano size, these receivers can fit just about anywhere!
Features
- Built-in WIFI so you can upgrade firmware by WIFI and configure the Receiver via the built-in WebUI with your PC or mobile phone
- Upgraded rigid antenna with greater durability and performance
- Improved PCB design is better for heat dissipation
- Solder pads are improved and easier to solder to
- UFL antenna socket for full-range antenna use
- Low-latency and high-refresh-rate RF module
- Open-source receiver based on ExpressLRS
- LED on the top side of PCB
- SX1280 RF chip
- ESP8285 MCU
![RadioMaster RP1 ExpressLRS 2.4ghz Nano Receiver T-Antenna Infographic](https://cdn.getfpv.com/media/wysiwyg/Antennas/Untitled_design_-_2022-09-26T220748.552.jpg)
Specifications
- Maximum receive refresh rate: 500Hz / F1000Hz
- Firmware Version: ExpressLRS v2.4 pre-installed
- Item: RP1 Nano ExpressLRS 2.4GHz Receiver
- FW Target: RadioMaster RP1/2 2400 RX
- Minimum receiver refresh rate: 25Hz
- Antenna: 65mm 2.4GHz T Antenna
- Weight: 2.2g (Including antenna)
- Dimension: 13mm*11mm*3mm
- Working voltage: 5v
- Bus interface: CRSF
- Type: ISM
Includes
- 1x RP1 ExpressLRS 2.4GHz Nano Receiver
- 1x 65mm UFL 2.4GHz T Antenna
- 1x User Manual
