About this product
The RCINPOWER GTS V3 1002 is a lightweight, smooth, and powerful motor made for ultralight toothpick drones.
Features
- Teal and Pink design
- 2.5g in weight
- 1002 Stator
Specifications
14000KV
- Motor Dimensions: 13.5×7.75mm
- Max Continuous Current: 9A
- Stator Dimensions: 10x2mm
- Internal Resistance: 175mΩ
- Mounting Pattern: 9x9mm
- Shaft Diameter: 1.5mm
- ldle Current@5V: .8A
- Configuration: 9N12P
- Input Voltage: 1-2S
- Weight: 2.5g
- Kv: 14000
19000KV
- Motor Dimensions: 13.5×7.75mm
- Max Continuous Current: 11.8A
- Stator Dimensions: 10x2mm
- Internal Resistance: 89mΩ
- Mounting Pattern: 9x9mm
- Shaft Diameter: 1.5mm
- ldle Current@5V: 1.3A
- Configuration: 9N12P
- Input Voltage: 1S
- Weight: 2.5g
- Kv: 19000
22000KV
- Efficiency Current: 2-4A ( More than 84%)
- Max. Current: 14A (3S) Max.
- Max. Con. Power: 52W (3S)
- Internal Resistance: 75mΩ
- Idle Current: 1.5A @ 5V
- Stator Diameter: 10mm
- Shaft Diameter: 1.5mm
- Input Voltage: 1S Lipo
- Configuration: 9N12P
- KV: 22000KV
- Weight: 2.5g
Includes
- 1x RCINPOWER GTS V3 1002 Motor (Choose 14000KV, 19000KV, or 22000KV)
- 1x Hardware Set
