The default is Joystick control mode.
the RunCam Phoenix 2 produces vivid high-resolution pictures.
performance is even better than the RunCam Eagle.
less red lens flare and less purple fringing effect.
less digital shimmer and a much cleaner image.
and is wonderful for freestyle flying!
Thanks Joshua for demonstrating his favorite camera Phoenix 2 Joshua Edition!
Dimensions
Package
- 1x Camera
- 1x ABS bracket1x 6pin FPV silicone cable
- 1x Set of screws1x Manual
Model | RunCam Phoenix 2 | ||
Image Sensor | 1/2″ CMOS Sensor | ||
Horizontal Resolution | 1000TVL | ||
Lens | 2.1mm (M12) FOV155° (4:3) | ||
Screen Format | 4:3 / 16:9 switchable | ||
Mirror/Flip | Available | ||
Signal System | PAL / NTSC Switchable | ||
S/N Ratio | >50dB (AGC OFF) | ||
Electronic Shutter Speed | Auto | ||
Auto Gain Control (AGC) | Auto | ||
Min. Illumination | 0.001Lux@1.2F | ||
WDR | Global WDR | ||
Day/Night | Color/BW/EXT/Auto | ||
Menu Control | Cable Control | ||
Power | DC 5-36V | ||
Current |
| ||
Housing Material | ABS | ||
Net Weight | 9g | ||
Dimensions | 19mm*19mm*19mm |
